channel

2 channels

  Wavelength range

1310/850nm or 1310/1550nm

Insertion loss

<4dB

Insertion loss WOW

<1db

Return loss

15dB

Speed

100 rpm

Pulling stength

10 N

Life

200 million revolutions

Estimated life cycle

23 dBm

Working temp.

-40 to 72 C

Storage temp.

-45 to 75 C

Torque

 <0.2 Nm

Fiber types

Ф3.0 Fiber cable or armor

Connector types

FC, SC, ST, SMA, or LC (and APC finishes)

Housing meterial

Stainless steel

Size

OD20*L65（mm）

Weight

100 g

IP rating

IP65
